Backyard Discovery HILLCREST - Page 48

2 3/4 in
[69 mm]
TYPICAL SPACING
STEP 19 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
20 H100088
SCREW PFH 8x1-1/8"
WALL BOARD - W4L16061
5/8"x3 3/8"x29 5/8" (16x86x752)
M24
(x5)
SIDE VIEW
M24 (x5)
088 (x20)
SCREW - 1 1/8"
USE A6P00410 PICKET PAL FOR SPACING
48
