Backyard Discovery HILLCREST - Page 63

STEP 34 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
4
H100088
SCREW PFH 8x1-1/8"
MENDING PLATE - W4L16077
5/8"x2 3/8"x5" (16x60x126)
N02
(x2)
N02 (x1)
N02 (x1)
088 (x2)
SCREW - 1 1/8"
088 (x2)
SCREW - 1 1/8"
FRONT VIEW
CORRECT ASSEMBLY
63
