NOTE:
USE 1 1/4" BOLTS TO FASTEN EACH
SIDE OF THE SLIDE SUPPORT TUBES.
009 (x4)
BOLT - 1 1/4"
TIP:
HAVIN
G A HELPER HOLD THE SLIDE
ASSEMBLY TOGETHER WHILE YOU FASTEN
WILL MAKE IT EASIER TO ASSEMBLE.
STEP 5 - SLIDE
QTY
PART NUMBER DESCRIPTION
4 H100009 BOLT WH 5/16x1 1/4
80
