STEP 53
WASHER
LOCK EXT
8x19 BLK
(8)
WASHER LOCK EXT 8x19 BLK
(8 PLCS)
LAG SCREW WH 5/16x2 BLK
(8 PLCS)
H8
H10
H8 - FLOOR RAIL - W4L06437
1"x3 3/8"x52 1/2" (24x86x1335)

H10 - FLOOR RAIL - W4L06439
1"x3 3/8"x54 1/2" (24x86x1383)

LAG SCREW
WH 5/16x2
BLK
(8)
NOTE HOLE LOCATION FOR
PROPER INSTALLATION.
T-NUT 5/16 BLK
(2 PLCS)
T-NUT 5/16
BLK
(2)
