STEP 73
NOTE HOLE
LOCATION
FOR PROPER
INSTALLATION.
FRONT
WASHER
LOCK EXT
8x19 BLK
(6)
BOLT WH 5/16x1 3/4 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
T-NUT 5/16 BLK
(2 PLCS)
T-NUT 5/16 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
BOLT WH 5/16x2-1/4 BLK
(2 PLCS)
BOLT WH
5/16x1 3/4
BLK
(2)
BOLT WH
5/16x2-1/4
BLK
(2)
T-NUT 5/16
BLK
(4)
E12
E11
E12
E11
E11 - RIGHT FORT UPRIGHT - W4L06475
1 3/8"x3 3/8"x23 3/4" (36x86x602)

E12 - LEFT FORT UPRIGHT - W4L06476
1 3/8"x3 3/8"x23 3/4" (36x86x602)

LAG SCREW WH 5/16x1 1/2 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
LAG SCREW
WH 5/16x1 1/2
BLK
(2)
