Backyard Discovery MALIBU - Page 127

STEP 79
FRONT
SCREW PFH
8x1 1/8
(36)
H12 M25 H12M29
M27
M27
M28
SCREW PFH 8x1 1/8
(12 PLCS)
T-NUT 5/16 BLK
(6 PLCS)
SCREW PFH 8x1 1/8
(12 PLCS)
SCREW PFH 8x1 1/8
(12 PLCS)
BOLT WH 5/16x1 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
NUT BARREL WH 5/16x5/8 BLK
(2 PLCS)
WASHER LOCK EXT 12x19 BLK
(2 PLCS)
T-NUT 1/4 BLK
(1 PLC)
DRILL A
P 5/16" HOLE FOR 1/4" HARDWARE.
90° L-BRACKET - BLK
(1 PLC)
BOLT WH 1/4x1 BLK
(1 PLC)
BOLT WH 1/4x5/8 BLK
(1 PLC)
NUT BARREL WH 1/4x5/8 BLK
(1 PLC)
WASHER LOCK EXT 8x15 BLK
(1 PLC)
BOLT WH 5/16x1 1/2 BLK
(6 PLCS)
WASHER LOCK EXT 8x19 BLK
(6 PLCS)
NUT BARREL
WH 1/4x5/8
BLK
(1)
WASHER
LOCK EXT
8x19 BLK
(8)
BOLT WH
1/4x5/8 BLK
(1)
T-NUT 5/16
BLK
(6)
WASHER
LOCK EXT
8x15 BLK
(1)
T-NUT 1/4
BLK
(1)
BOLT WH
5/16x1 1/2
BLK
(6)
BOLT WH
1/4x1 BLK
(1)
WASHER
LOCK EXT
12x19 BLK
(2)
NUT BARREL
WH 5/16x5/8
BLK
(2)
H12 - WALL BOARD - W4L06472
1"x3 3/8"x48" (24x86x1219)

M27 - WALL BOARD - W4L06534
5/8"x3 3/8"x48" (16x86x1219)

- 90° L-BRACKET - BLK - A4M00555

M25 - WALL BOARD - W4L06477
5/8"x3 3/8"x48" (16x86x1219)

M29 - WALL BOARD - W4L06536
5/8"x3 3/8"x8 1/4" (16x86x210)

M28 - WALL BOARD - W4L06535
5/8"x3 3/8"x29 7/8" (16x86x760)

BOLT WH
5/16x1 BLK
(2)
127
