STEP 87
2 1/2" TYP
(5 SPCS)
O2
1 1/2" TYP
SCREW PFH 8x1 1/8
(10 PLCS)
SCREW PFH
8x1 1/8
(10)
O2 - PICKET - W4L06407
5/8"x1 3/8"x18 3/4" (16x34x476)

135
