STEP 91
BACK
SCREW PFH
8x1 1/8
(4)
SCREW PFH 8x1 1/8
(2 PLCS)
SCREW PFH 8x1 1/8
(2 PLCS)
6 1/2"
M1
M1 - GROWTH BOARD - W4L06143
5/8"x3 3/8"x60 1/4" (16x86x1530)

139
