Backyard Discovery MALIBU - Final Play Set Components; 10 Ft Slide Assembly

CB
STEP 102
 10 FT. SLIDE ASSEMBLY
BOLT WH 5/16x1/2
(3 PLCS)
T-NUT 5/16
(3 PLCS)
9"
6 1/2" 6 1/2"
5 3/8"
1"
10 FT. SLIDE - DRILLING PATTERN
DRILL THROUGH
USING A 7/16"
DRILL BIT.
T-NUT 5/16 (3)
BOLT WH
5/16x1/2
(3)
