Backyard Discovery MALIBU - Page 54

STEP 6
SCREW PFH 8x2 1/4
(2 PLCS)
T-NUT 5/16 BLK
(2 PLCS)
BOLT WH 5/16x2-1/4 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
J1
E5
SCREW PFH
8x2 1/4
(2)
T-NUT 5/16
BLK
(2)
BOLT WH
5/16x2-1/4
BLK
(2)
WASHER
LOCK EXT
8x19 BLK
(2)
E5 - RAIL UPRIGHT - W4L06398
1 3/8"x3 3/8"x35 7/8" (36x86x912)

J1 - FLOOR SUPPORT BLOCK - W4L06403
1"x2 3/8"x3 3/8" (24x60x86)

54
