Backyard Discovery MALIBU - Roof Structure and Panel Attachment

STEP 26
FRONT
LEFT
BACK
RIGHT
BOLT WH 1/4x1 BLK
(4 PLCS)
WASHER LOCK EXT 6x15 BLK
(4 PLCS)
NUT BARREL WH 1/4x7/8 BLK
(4 PLCS)
WASHER LOCK EXT 8x15 BLK
(4 PLCS)
L3
L3
L3
BOLT WH
1/4x1 BLK
(4)
NUT BARREL
WH 1/4x7/8
BLK
(4)
WASHER
LOCK EXT
8x15 BLK
(4)
WASHER
LOCK EXT
6x15 BLK
(4)
L3 - GABLE BOARD - W4L06412
5/8"x4 3/8"x25 3/8" (16x112x644)

74
