Backyard Discovery MALIBU - Page 99

STEP 51
K5 - GROUND BOARD - W4L06430
5/8"x5 1/4"x55 5/8" (16x134x1412)

BOLT WH
5/16x2-1/2
BLK
(4)
BOLT WH
5/16x2-1/4
BLK
(4)
BOLT WH
5/16x1 3/4
BLK
(5)
T-NUT 5/16
BLK
(13)
WASHER
LOCK EXT
8x19 BLK
(13)
BOLT WH 5/16x1 3/4 BLK
(1 PLC)
WASHER LOCK EXT 8x19 BLK
(1 PLC)
T-NUT 5/16 BLK
(1 PLC)
M23
T-NUT 5/16 BLK
(4 PLCS)
WASHER LOCK EXT 8x19 BLK
(4 PLCS)
BOLT WH 5/16x2-1/4 BLK
(4 PLCS)
BOLT WH 5/16x1 3/4 BLK
(4 PLCS)
BOLT WH 5/16x2-1/2 BLK
(4 PLCS)
WASHER LOCK EXT 8x19 BLK
(4 PLCS)
WASHER LOCK EXT 8x19 BLK
(4 PLCS)
T-NUT 5/16 BLK
(4 PLCS)
T-NUT 5/16 BLK
(4 PLCS)
NOTE HOLE LOCATION FOR
PROPER INSTALLATION.
E7
E9
H6
K5
K7
E7 - FRONT LEFT UPRIGHT - W4L06425
1 3/8"x3 3/8"x84" (36x86x2134.5)

E9 - FRONT RIGHT UPRIGHT - W4L06427
1 3/8"x3 3/8"x84" (36x86x2134.5)

H6 - FLOOR RAIL - W4L06435
1"x3 3/8"x76 7/8" (24x86x1952)

K7 - GROUND BOARD - W4L06432
5/8"x5 1/4"x78" (16x134x1981)

M23 - WALL RAIL - W4L06467
5/8"x3 3/8"x3 3/8" (16x86x86)

NOTE HOLE LOCATION FOR
PROPER INSTALLATION.
K5
