Backyard Discovery Mount Triumph - Page 59

STEP 13
SCREW PFH
8x2 BLK
(2)
SCREW PFH
8x1 1/4 BLK
(4)
TOP VIEW
T-NUT 1/4 BLK
(2 PLCS)
BOLT WH 1/4x1/2 BLK
(1 PLC)
NUT BARREL WH 1/4x7/8 BLK
(1 PLC)
BOLT WH 1/4x5/8 BLK
(2 PLCS)
SCREW PFH 8x1 1/4 BLK
(2 PLCS)
SCREW PFH 8x2 BLK
(2 PLCS)
SCREW PFH 8x1 1/4 BLK
(2 PLCS)
T3
T3
J9
90° L-BRACKET - BLK
(2 PLCS)
T-NUT 1/4
BLK
(2)
NUT BARREL
WH 1/4x7/8
BLK
(1)
BOLT WH
1/4x5/8 BLK
(2)
BOLT WH
1/4x1/2 BLK
(1)
J9 - FLOOR JOIST - W4L07603
1"x2 3/8"x20 1/4" (24x60x513)

T3 - SUPPORT BOARD - W4L07601
1"x1 3/8"x18 3/4" (24x34x477)

- 90° L-BRACKET - BLK - A4M00555
(2)
