Backyard Discovery Mount Triumph - Page 69

STEP 23
SCREW PFH 8x1 3/4 BLK
(4 PLCS)
T-NUT 5/16 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
LAG SCREW WH 5/16x2 BLK
(2 PLCS)
WASHER LOCK EXT 8x19 BLK
(2 PLCS)
BOLT WH 5/16x1 3/4 BLK
(2 PLCS)
LAG SCREW WH 1/4x2 BLK
(2 PLCS)
WASHER LOCK EXT 6x15 BLK
(2 PLCS)
J5
J5
J3
J4
J4
J3
J3 - BENCH SUPPORT - W4L07586
1"x2 3/8"x9" (24x60x230)

J4 - ANGLE BRACE - W4L07587
1"x2 3/8"x10" (24x60x254)

J5 - SUPPORT BLOCK - W4L07588
1"x2 3/8"x2 7/8" (24x60x72)

SCREW PFH
8x1 3/4 BLK
(4)
LAG SCREW
WH 5/16x2
BLK
(2)
WASHER
LOCK EXT
6x15 BLK
(2)
WASHER
LOCK EXT
8x19 BLK
(4)
LAG SCREW
WH 1/4x2 BLK
(2)
BOLT WH
5/16x1 3/4
BLK
(2)
T-NUT 5/16
BLK
(2)
68
