Backyard Discovery Mount Triumph - Page 75

V
STEP 29
T-NUT 5/16
BLK
(4)
SCREW PFH
8x1-1/2 BLK
(1)
BOLT WH
5/16x2 BLK
(3)
BOLT WH
5/16x2-3/4
BLK
(1)
WASHER
LOCK EXT
8x19 BLK
(4)
(1) WP10 - BENCH BACK ASSEMBLY - W2A02081
1 1/8"x11 7/8"x17 5/8" (27x303x615)
SCREW PFH 8x1-1/2 BLK
(1 PLC)
T-NUT 5/16 BLK
(1 PLC)
BOLT WH 5/16x2-3/4 BLK
(1 PLC)
WASHER LOCK EXT 8x19 BLK
(1 PLC)
T-NUT 5/16 BLK
(3 PLCS)
WASHER LOCK EXT 8x19 BLK
(3 PLCS)
BOLT WH 5/16x2 BLK
(3 PLCS)
F4
WP10
F4 - SUPPORT BLOCK - W4L07614
1 3/8"x2 3/8"x5 7/8" (36x60x148)

74
