Backyard Discovery Shenandoah 65413 - Page 14

Parts Identification
Wood Components
(NOT TO SCALE)
E1 - UPRIGHT - W104109
1 3/8"x3 3/8"x55 5/8" (36x86x1414)

E2 - UPRIGHT - W104101
1 3/8"x3 3/8"x89 1/2" (36x86x2272)

E3 - UPRIGHT - W104102
1 3/8"x3 3/8"x89 1/2" (36x86x2272)

E4 - UPRIGHT - W104103
1 3/8"x3 3/8"x89 1/2" (36x86x2272)

E5 - UPRIGHT - W104104
1 3/8"x3 3/8"x89 1/2" (36x86x2272)

E72 - LEFT RAIL - W100036
1 3/8"x3 3/8"x61 3/4" (36x86x1570)

E73 - RIGHT RAIL - W100037
1 3/8"x3 3/8"x61 3/4" (36x86x1570)

E77 - ANGLE BRACE - W100991
1 3/8"x3 3/8"x74 3/8" (36x86x1890)

F1 - SHELF BRACE - W104177
1 3/8"x2 3/8"x13 1/8" (36x60x332)

F2 - SHELF BRACE - W104164
1 3/8"x2 3/8"x16" (36x60x406)

F71 - STANDARD ANGLE BRACE - W100689
1 3/8"x2 3/8"x13" (36x60x330)

G1 - VERTICAL BENCH LEG - W104170
1"x5 1/4"x15 3/4" (24x134x400)

G2 - HORIZONTAL BENCH LEG - W104168
1"x5 1/4"x22" (24x134x560)

