Parts Identification
Wood Components
(NOT TO SCALE)
G3 - LEMONADE GABLE BOARD - W104151
1"x5 1/4"x29 7/8" (24x134x758)

G4 - FORT GABLE BOARD - W104150
1"x5 1/4"x39 7/8" (24x134x1014)

G5 - SHELF BOARD - W104178
1"x5 1/4"x43" (24x134x1092)

G6 - SHELF BOARD - W104179
1"x5 1/4"x43" (24x134x1092)

G7 - GROUND BOARD - W104108
1"x5 1/4"x44 1/4" (24x134x1124)

G8 - SWING BEAM MOUNTING BOARD - W104119
1"x5 1/4"x44 1/4" (24x134x1124)

G9 - SEAT BOARD - W104172
1"x5 1/4"x44 1/4" (24x134x1124)

G10 - LEMONADE ARCH BOARD - W104175
1"x5 1/4"x44 1/4" (24x134x1124)

G11 - GROUND BOARD - W104107
1"x5 1/4"x46 1/8" (24x134x1172)

G12 - GROUND BOARD - W104105
1"x5 1/4"x82" (24x134x2084)

G13 - GROUND BOARD - W104106
1"x5 1/4"x82" (24x134x2084)

H2 - BENCH SEAT SUPPORT - W104171
1"x3 3/8"x9 1/2" (24x86x240)

