EV - CLIMBING ROCK - GREEN - A100064

STEP 3
ATTACH EV ROCKS TO BOARDS USING 1/4"X1 1/4" BOLTS, LOCK WASHERS, AND 1/4"
T-NUTS.
BOLT PTH
1/4x1 1/4
(24)
WASHER
LOCK INT
8x15
(24)
T-NUT 1/4
(24)
BOLT PTH 1/4x1 1/4
3/&6
WASHER LOCK INT 8x15
3/&6
T-NUT 1/4
3/&6
(9
