TIP: PREBENDING THE ENDS WILL EASE ASSEMBLY.
USE M70 SLIDE BED SUPPORT AS A
TEMPLATE FOR DRILLING BOTTOM
HOLE PATTERN IN SLIDE BED. BE SURE
TO PLACE SLIDE BRACE UP 1/2" FROM
BOTTOM EDGE OF SLIDE BED BEFORE
MARKING HOLE PATTERN. USE A 3/8"
DRILL BIT TO DRILL HOLE PATTERN.
M70 - SLIDE BED SUPPORT - W100935
5/8"x3 3/8"x19 7/8" (16x86x505)
BOLT WH
5/16x1/2
(3)
WASHER
LOCK EXT
12x19
(3)
NUT BARREL
WH 5/16x5/8
(3)
STEP 1
Ɣ ATTACH SLIDE BED SUPPORT TO SLIDE USING HARDWARE SHOWN.
10 FOOT SLIDE ASSEMBLY
PHASE 1
(SEE SLIDE ASSEMBLY
INSTALLATION STEP FOR
DECK MOUNTING HOLE
DRILLING LOCATIONS).
DX - SLIDE BED 10' LIGHT GREEN
NUT BARREL WH 5/16x5/8
3/&6
WASHER LOCK EXT 12x19
3/&6
BOLT WH 5/16x1/2
3/&6
0
DX - SLIDE BED 10' LIGHT GREEN - A100035
