STEP 10
WASHER
LOCK EXT
8x19
(2)
NUT BARREL
WH 5/16x7/8
(2)
WASHER
LOCK EXT
12x19
(2)
NUT BARREL WH 5/16x7/8
3/&6
WASHER LOCK EXT 12x19
3/&6
WASHER LOCK EXT 8x19
3/&6
BOLT WH 5/16x1 1/4
3/&6
8
BOLT WH
5/16x1 1/4
(2)
U1 - WALL RAIL - W104147
3/4"x5 1/4"x37 3/8" (20x134x950)

