STEP 11
WASHER
LOCK EXT
8x19
(4)
BOLT WH
5/16x2 1/4
(2)
BOLT WH 5/16x2 1/4
3/&6
WASHER LOCK EXT 8x19
3/&6
LAG SCREW WH 5/16x2
3/&6
WASHER LOCK EXT 8x19
3/&6
LAG SCREW
WH 5/16x2
(2)
)
)
F71 - STANDARD ANGLE BRACE - W100689
1 3/8"x2 3/8"x13" (36x60x330)

