ROCK LADDER
ASSEMBLY
Ǣǻrƻˡ
ŗŷǻrʲ
1. Install T-nuts before attaching rocks.
2. Orient top edge of rocks with top edge of slats.
3. Fasten rocks as shown.
CLIMBING ROCK
GREEN SMALL
(6)
A100060
SCREW PFH
8x1 1/8
(6)
H100088
BOLT FA
3/8x1 1/2
(6)
H100001
T-NUT
3/8
(6)
H100073
˟˧˧ ʹɮ˥ʺ
ǢNNJrɟ˚ˠˠˀ˧˃
˟˟ˠ ʹɮ˥ʺ
Dŷĵǻ˚ˢˀ˧ɮˠˠˀˡ˃
˟˦ˢ ʹɮ˥ʺ
ǻ˚ŗȕǻ˚ˢˀ˧˃
˟˥˟ ʹɮ˥ʺ
NĵÝōDÝŗµNJŷNħµNJrrŗǢōĵĵ
