Backyard Play Systems 4431 - Fort Construction: Deck Planks

19
FORT
DECK CLEAT
Flush
Flush
EQUAL
EQUAL
EQUAL
EQUAL
3/4 x 2-1/2 x 45"
x1
2516-CC
2-1/2" Wood Screws
30 mm Wood Screws
(In center of planks)
x28
x14
FORT
DECK PLANKS
Flush
evenly spaced
x7
2961-CC
3/4 x 5-3/8 x 44-7/8"
Flush with
post.
To avoid splitting wood
pre-drill (2) 11/64" holes
2-1/2" Wood Screws
x4
3/8"
