Backyard Play Systems 4431 - Swing Beam Installation (Plate Attachment)

37
Flat Washer
Lock Nut
6-1/2" Carriage Bolt
Torque Washer
You may need to tap with
hammer to get though holes.
SWING BEAM ASSEMBLE
Flat Washer
Lock Nut
6-1/2" Carriage Bolt
Torque Washer
x1
x1
x2
Position swing beam assembly resting upon
plate and align with holes.
2485
x1
NOTE: You may need to tap bolts
with hammer to get though holes.
Clean all debris from bolt threads
before installing lock nuts
SWING BEAM INSTALL
8-1/2" Carriage Bolt
x1
