3-3/4" Carriage Bolt
Flat Washer
Lock Nut
x4
x4
DO NOT FULLY TIGHTEN
CARRIAGE BOLTS AT THIS TIME
Align holes and insert carriage bolt.
Repeat where arrows are shown.
NOTE: You may need to tap bolts
with hammer to get though holes.
Clean all debris from bolt threads
before installing lock nuts
SWING BEAM ASSEMBLE
SWING BEAM ASSEMBLE
Position swing beam assembly resting upon A-frame.
