Backyard Play Systems 4431 - Fort: Ladder Side Balusters

41
LADDER SIDE BALUSTERS
LADDER SIDE BALUSTERS
FORT
FORT
INSTALLATION:
FROM INSIDE FORT
INSTALLATION:
FROM INSIDE FORT
VIEW
VIEW
30 mm
Wood Screws
x16
30 mm
Wood Screws
x36
x4
2523-CC
5/8 x 3-1/4 x 29-3/4"
x9
1813-CC
5/8 x 3-1/4 x 17"
13/16"
1" T Y P. 1" T Y P.
13/16" 13/16"
13/16"
INSIDE VIEW
3 x 3"
3 x 3"
INSIDE VIEW
BEGIN
HERE
BEGIN
HERE
Flush
Flush
