TERRACE DECK PLANKS
TERRACE DECK PLANKS
2-1/2" Wood Screws
x24
30 mm Wood Screws
x12
End Screws: 2-1/2" (24)
End Screws: 2-1/2"
Middle Screws: 30 mm (12)
x6
3/4 x 5-3/8 x 30-1/2"
1819-CC
Ensure equal spacing
of deck planks before
installing wood screws.
Top View
Equally spaced
Flush
Note hole
location.
2-1/2" Wood Screws
x8
30 mm Wood Screws
x4
End Screws: 2-1/2" (8)
End Screws: 2-1/2"
Middle Screws: 30 mm (4)
x2
3/4 x 5-3/8 x 30-1/2"
1818-CC
Ensure deck planks are  ush
with side rails before installing
wood screws.
Top View
Flush with outer rails
