Backyard Play Systems 4431 - Terrace Assembly: Deck Planks (Part 2); Terrace Assembly: Balusters

49
TERRACE DECK SUPPORT & BAR TOP
TERRACE DECK SUPPORT
2-1/2" Wood Screws
x4
1-3/4" Wood Screws
x6
Flush to bottom of
1821-CC deck rail.
Screws into baluster top rails.
x1
5/8 x 5-3/8 x 33"
1816-CC
x1
3/4 x 2-1/2 x 42-1/2"
1825-CC
Top View
15-1/8"
15-1/8"
Flush
2490-CC
2490-CC
x1
1-1/2 x 2-1/2 x 24"
2490-CC
2-1/2" Wood
Screws
x3
Center 2490-CC on
seam of two 1821-CC
CENTER 2490-CC
ON 1821-CC's
1821-CC
1821-CC
2-5/8"
CENTER CENTER
2-1/2"
Wood
Screws
TERRACE
Pre-drill 1/8" holes
to avoid splitting.
to
center
to
center
Pre-drill 1/8" holes
to avoid splitting
2-1/2" Wood Screws
x2
2490-CC
Pre-drill 1/8"
holes to avoid
splitting
