Backyard Products GABLE - PARTS IDENTIFICATION AND SIZES; WOOD SIZE CONVERSION CHART; PARTS LIST BY CATEGORY

PARTS IDENTIFICATION AND SIZES
DOOR TRUSSTRIM WALL
Treated lumber is stamped:
6 x 24" (15 x 61 cm)
x6 x4 x4
PARTS LIST
INVENTORY YOUR PARTS before you begin.
We suggest sorting parts by the category they are listed in.
ZJ
x1
5/8 x 3 x 72" (1,6 x 7,6 x 183 cm)
WOOD SIZE CONVERSION CHART
Nominal Board Size Actual Size
1 x 4
.................3/4" x 3-1/2" (1,9 x 8,9 cm)
2 x 4 ..............1-1/2" x 3-1/2" (3,8 x 8,9 cm)
2 x 3 ..............1-1/2" x 2-1/2" (3,8 x 6,3 cm)
1 x 3 .................3/4" x 2-1/2" (3,8 x 6,3 cm)
10x8' 10x12' 10x16'
x1
2 x 3 x 22-1/8" (5 x 7,6 x 56 cm)
LT
x4
2 x 3 x 72" (5 x 7,6 x 183 cm)
OY
x4
7/16 x 2-1/2 x 24-3/4" (1,1 x 6,3 x 62,9 cm)
7/16 x 2-1/2 x 48" (1,1 x 6,3 x 122 cm)
x4 x4
7/16 x 2-1/2 x 22-1/2" (1,1 x 6,3 x 57,2 cm)
x6 x4 x4
2 x 3 x 69" (5 x 7,6 x 175,3 cm)
OV
x4
2 x 3 x 77" (5 x 7,6 x 196 cm)
PB
x2
2 x 3 x 92-5/8 " (5 x 7,6 x 235,3 cm)
PM
x2
2 x 3 x 94-1/2" (5 x 7,6 x 240 cm)
PR
2 x 4 x 65-7/8" (5 x 10 x 167 cm)
x6 x4 x4
CV
5/8 x 4 x 14" (1,6 x 10 x 35,6 cm)
x8
WNA
2 x 3 x 58" (5 x 7,6 x 147,3 cm)
x4
CDD
1 x 3 x 94-3/4"
(2,5 x 7,6 x 240,1 cm)
x2 x2 x2
HS
1 x 3 x 94-3/4"
(2,5 x 7,6 x 240,1 cm)
x2 x2
FO
2 x 3 x 46-1/4" (5 x 7,6 x 117,5 cm)
x2
NH
2 x 3 x 48" (5 x 7,6 x 122 cm)
x2 x2
NK
Part identication is
stamped on some parts.
• Check these locations for part stamp.
RS
RS
x4
1 x 3 x 7-1/2" (2,5 x 7,6 x 19 cm)
GBB
x4
3/4 x 5-1/8 x 8-3/8" (1,9 x 13 x 21,3 cm)
LEFT PAINTED GREEN
RIGHT PAINTED RED
x2 x4
10x8' 10x12' 10x16'
3
1 x 3 x 5" (2,5 x 7,6 x 12,7 cm) USED AS A GAUGE BLOCK FOR 3/4" (19 mm) MEASUREMENT
x1
GAA
3/4"
(19 mm)
XMA
x1
11/16 x 2-1/2 x 60-5/8" (1,7 x 6,3 x 154 cm)
x1 x1
OO
x2
1-1/4 x 2-1/2 x 69" (3,2 x 7,6 x 175,3 cm)
