Backyard LIGHTNING RIDGE 2200159 User Manual

STEP 4 - ROCK WALL
TIP:
INSTALL T-NUTS IN WOOD FIRST
QTY
PART NUMBER DESCRIPTION
2 H100074 T-NUT 5/16
4
H100111
SCREW PFH 8x2"
ATTACHMENT BOARD - W4L16159
1"x3 3/8"x23 1/2" (24x86x596)
H75
(x1)
074 (x2)
T-NUT - 5/16"
H75 (x1)
111 (x4)
SCREW - 2"
H75
T-NUTS TO THE INSIDE OF
BOARD WHEN INSTALLED
SIDE VIEW
T-NUT
22
