Backyard YardLine ASTON - FRONT WALL PANELS

3/8 x 48 x 96"
(1 x 121,9 x 243,8 cm)
x1
19
5-1/2"
(14 cm)
PARTSREQUIRED:
FRONT WALL PANELS
x40
2" (5,1 cm)
DOOR
Place 48x96" left panel primed side up onto wall frame centered in door
opening as shown.
• Ensure top of panel is overhanging the top of frame by 5-1/2".
Nail panel with two 2" nails 6" (15,2 cm) apart. Maintain 64" (162,5 cm) measurement
between studs and square frame.
2
1
MAINTAIN64"DIMENSION
BETWEENSTUDS
Handlepanelswithcaretoavoidbreakage.
Hold the 3/4" measurement along left edge of panel. Use a gauge block.
Forsquarenessmaintain
3/4"measurementalong
paneledge.
Primed
sideup
CENTER
CENTER CENTER
3/4"GAUGE
BLOCK
Handlepanelswithcaretoavoidbreakage.
3/4"GAUGE
BLOCK
UNTILFRONTPANELSARE
INSTALLED,HANDLECAREFULLY
TOAVOIDBREAKINGATCORNERS
ANDEDGES.
6"
(15,2 cm)
3/4"
(1,9cm)
BEGINHERE
Maintain
Square
