Backyard YardLine ASTON - Page 20

3/8 x 48 x 96"
(1 x 121,9 x 243,8 cm)
x1
OO
x1
2 x 3 x 69" (5,1 x 7,6 x 175,3 cm) TEMPORARY SUPPORT
20
Flush
Flush
6"
(15,2 cm)
PARTSREQUIRED:
FRONT WALL PANELS
x40
2" (5,1 cm)
InstallOOafterpanels
fortemporarybrace.
DOOR
x2
3" (7,6 cm)
5-1/2"
(14 cm)
Place 48x96" right panel primed side up onto wall frame ush to left panel.
Nail panel with two 2" nails 6" (15,2 cm) apart. Maintain 64" (162,5 cm)
measurement between studs and square frame.
4
5
3
Use OO as a brace to maintain 64" (162,6 cm) opening. Use two 3" screws
to attach.
MAINTAIN64"DIMENSION
BETWEENSTUDS
Hold the 3/4" measurement along right edge of panel. Use a gauge block.
3"(7,6cm)
Screw
3"(7,6cm)
Screw
Primed
sideup
Forsquarenessmaintain
3/4"measurementalong
paneledge.
3/4"GAUGE
BLOCK
3/4"
(1,9cm)
Maintain
Square
3/4"GAUGE
BLOCK
