Backyard YardLine ASTON - Page 21

3/8 x 11-7/8 x 96" (1 x 30,5 x 243,8 cm)
x2
21
DOOR
6"
(15,2 cm)
PARTSREQUIRED:
FRONT WALL PANELS
x60
2" (5,1 cm)
Flush
FlushFlush
Flush
DOOR
5-1/2"
(14 cm)
5-1/2"
(14 cm)
MAINTAIN64"DIMENSION
BETWEENSTUDS
Repeat steps 6 and 7 to attach the right panel.
8
10
Place 11-7/8x96" panel onto wall frame ush to left 48x96" panel with
primed side up as shown.
• Ensure top of panel is overhanging the top of frame by 5-1/2".
Nail the panel using 2" nails 6" apart on edges.
7
6
6"
(15,2 cm)
You have nished building your front wall.
FINISH
9
Carefully ip the FRONT WALL over.
Primed
sideup
Primed
sideup
