Backyard YardLine ASTON - BACK WALL INSTALLATION

DOOR
22
2" (5,1 cm)
PARTSREQUIRED:
DOOR
First, nail lower edge of panel to oor frame using 2" nails 6" apart.
Angle nail to hit oor frame (Fig.A).
2
You have nished standing your BACK WALL.
FINISH
5
Secure side wall bottom plate to oor using 3" nails (Fig.A).
3
3" (7,6 cm)
x10
x22
BACK WALL INSTALLATION
DOOR
3"Nailsintobottomplate.
BEGIN
Stand backwall on oor.
It is important to secure the backwall in the following order.
ENSURE4"MEASUREMENTISATTOPOFBACKWALLASSEMBLY.
Center back wall assembly on the 120" oor dimension.
1
120"
(304,8 cm)
4"
(10,2 cm)
Nail2"nailsrst.
2"(5,1cm)
Nails
3"(7,6cm)
Nails
Fig.A
