Backyard YardLine ASTON - DOOR HARDWARE

47
1-1/2"(3,8cm)
Screws
SET
SCREW
You have nished installing your T-handle and decorative hinges.
FINISH
4
Attach inside handle and secure with set screw as shown.
3
Insert handle in hole and secure using 1-1/2" (3,8 cm) screws.
2
35-3/4"
90 cm
RIGHTDOOR.
1-1/2"
3,8 cm
TOPVIEW
1/4"Pre-drilland
1/2"Drill-through.
DOOR HARDWARE
x1
x2
PARTSREQUIRED:
1-1/2" (3,8 cm)
Re-drill hole with 1/2" drill.
Keep drilled hole square to
trim to avoid breaking edge
of 2x3".
BEGIN
1
Measure and mark location of hole on outside of right door as shown (Fig.A).
Pre-drill hole with 1/4" drill.
1/2" (1,3 cm) Drill Bit
1/4" (0,6 cm) Drill Bit
Fig.A
1-1/2" (3,8 cm)
