CHAPTER 1 INTRODUCTION1022H TRACTOR
8. SPECIFICATIONS
MODEL 1022H
Engine
Maker YANMAR
Model 3TNV74F
Type Water cooled 4 cycle, 3 cylinder diesel
Out put (KW (ps)/rpm) 16(21.7) / 3,200
Number of Cylinder 3
Displacement 993 cc
Bore and Stroke 74 mm x 77mm
Compression ratio 23.1 : 1
Firing order 1-3-2
Rated Speed (rpm) 3,200
Engine rpm range 1,400 ~ 3,415 rpm
Fuel Injection Pump Type Indirect Injection
Lubrication type Forced circulation
Engine Oil Capacity (Standard) 1.8ℓ (0.48 US gal)
Cooling system Water cooled, Forced circulation
Coolant capacity 3.5ℓ ( 0.93 US gal)
Air cleaner Dry Single Element
Mufer Horizontal
Fuel Diesel fuel (Use ultra low)
Fuel Tank capacity 25ℓ (6.6 US gal)
Electrical
Battery 12V 45Ah
Starting system Starter motor with pre-heater
Starter Capacity 12V – 1.0 (1.4)KW
Alternator 12V - 40Amp
Clutch
Main Clutch Dry Single Disc, Mechanic (Flange type)
Drive Train
Transmission
Hydraulic + Mechanical
H/L with Sliding-mesh
MFWD (4WD) Standard
Differential lock Bevel gears with diff-Lock
Brakes Wet disc brake, mechanical
Steering Hydraulic Power
Axle type
Front Center pin
Rear Central axle
