HOW TO USE THIS MANUAL
This manual is intended for technicians with mid to high level of service knowledge and skills for BAD BOY
TRACTORS. Make sure to understand this manual fully for rapid and accurate inspection and service.
This manual is a single book for the 1022H TRACTOR and contains several useful chapters such as Introduction,
Disassembly and reassembly of major point, Engine accessories, HST system, Transmission, Front axle (4WD), Rear
axle and Brakes, Power steering system, Hydraulic system and Electric accessories and instruments and diagrams
in this manual are described based on the standard model so they may be different from your vehicle due to different
specications by models. However, the same instructions should be followed for service.
This manual is structured as follows:
CHAPTER 2 DISASSEMBLY AND REASSEMBLY OF MAJOR POINT 1022H TRACTOR
K19W026A
FIG. 2-7 Starter motor/Alternator
4. Disconnect the engine harness from the
alternator, starter motor, water temperature
sensor, oil pressure.
K19W029A
FIG. 2-10 Air cleaner assembly
7. Remove the air cleaner inlet pipe.
Remove the inlet/outlet pipes from radiator.
B22W-202010
2
-
10
K19W028A
FIG. 2-9 Fuel hoses
6. Remove the fuel hoses and assembly.
NOTE
• It is better for the lower nuts of mounting
rubbers to be removed completely and the
upper nuts should be removed slightly in or-
der to reassemble the engine easily.
1
2
3
4
5
To Next Page
