CHAPTER 1 INTRODUCTION 1022H TRACTOR
10.4.2 TRANSMISSION
Inspection
items
Daily
Inspection and servicing intervals
Hour of operation
(X10 on hour meter)
Intervals after that Judgment criteria mm (in)
5 10 15 20 25 30 35 40 45 50 55 60
Transmission
oil
○●★●
Every 200 hours or
12months after rst 50
hours
Clean hydraulic suction
lter at the same time.
Brake pedal
free play
○
Check daily Free Play:30 to 40mm
Brake
performance
○
Check daily
Interlocked brakes should
work simultaneously
Lever
performance
○
Check daily
Every lever should work
positively
Steering
wheel free
play
○
Check daily
About 50mm (1.97) on
circumstance
Toe - in
★★
Check after every 300 hrs
2 to 6mm
(0.078 ~ 0.236 in)
Retightening
ball joints
of steering
system
○○○
Check after every 300 hrs
Grease in
front axle
hinge pin
○○
Grease every 300 hrs
Grease each
nipple
○○○○○○○○○○○○
Replenish every 50
hrs (Everyday in dusty
condition)
Wheel
tightening
bolts and nuts
○
Check daily
F (9/16-18UNF)
R (1/2-20UNF)
SAE J429 Grade 5
All should be tighten
(lb.ft / kgf.cm)
Front : 121 / 1660
Rear : 84.9 / 1167
Loose bolts
and nuts
○
All should be tighten
Electric wiring
○○○
Check every year All should work properly.
Operation
of the
instrument
○
Check daily
Electric
apparatuses
Check every year All should work properly
Adjusting
throttle lever
★★
Check after 300 hours
○ Inspection, Replenish, and Adjustment
● Replacement △ Cleaning and/or washing
★ Consult your Dealer
To Next Page
