CHAPTER 1 GENERAL INFORMATION 4025H/4035H/4035CH TRACTOR
3.4 USING STANDARD PART AND ADHESIVE
1. When replacing a worn or damaged part, use a
new part that meets the international standard.
2. When replacing a packing or O-ring, fit a new
one. Before installation, apply grease to the
O-ring or oil seal ring.
3. When assembling a snap ring on a shaft or in a
hole, ensure its sharply angled side to point the
directionofforceasshownintherstgure.
4. When installing a spring pin, insert its split
portion in the direction to be forced as described
inthesecondgureabove.
6. When the oil grooves are engaged with the
thrust washer, be careful with assembly.
6015W114A
5. Replace the split pin with a new one and fix it
rmly.
6015W115A
6015W116A
Oil groove
6015W113A
Snap ring for shaft
Snap ring for hole
Section applied
with force
