Service Parts Manual
OPERATOR PROTECTION SYSTEM
Page R-4
Service Parts Manual
634510 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 631578 OPS UPPER KIT (INCLUDES ITEMS 2 - 7)................................................... 1
2 631576 UPPER WELD UNIT ............................................................................... 1
3 629082 FRONT CONNECTOR (DRIVER SIDE)................................................... 1
4 629081 FRONT CONNECTOR (PASSENGER SIDE) .......................................... 1
5 609080 REAR CONNECTOR (DRIVER SIDE) ..................................................... 1
6 609079 REAR CONNECTOR (PASSENGER SIDE)............................................. 1
7 629328 UPPER OPS HARDWARE KIT (INCLUDES ITEMS 8 - 9) ...................... 1
8 630642 HEX HEAD BOLT, 3/8" - 16 X 2 1/2" LG............................................ 16
9 630643 LOCK NUT, 3/8" - 16.......................................................................... 16
10
11
12 631664 ACCESSORIES OPS KIT (INCLUDES ITEMS 13 - 24) ................................. 1
13 611774 GRAB HANDLE........................................................................................ 2
14 612254 GRAB HANDLE MOUNT.......................................................................... 4
15
16
17 631579 OPS ACCESSORY HARDWARE KIT (INCLUDES ITEMS 18 - 21) ........ 1
18 610753 HEX HEAD BOLT, 7/16" - 20 X 1" LG................................................ 4
19 609569 HEX HEAD BOLT, 7/16" - 20 X 3/4" LG............................................. 4
20 00734G3 LOCK NUT, 7/16" - 20........................................................................ 6
21 612255 PAN HEAD TORX SCREW, #12 - 14 X 1" LG ................................... 4
22
23 629454 SIDE DOOR NET (PAIR) (NOT ILLUSTRATED)...................................... 1
24 632116 SEAT BELT RETRACTOR ....................................................................... 2
25 * SEAT BELT D-RING ....................................................................................... 2
26 * SEAT BELT ATTACH PLATE .......................................................................... 2
27 * SEAT BELT D-RING COVER.......................................................................... 2
To Next Page
