THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
Service Parts Manual
ACCELERATOR
Page A-2
Service Parts Manual
634510 Service Parts Manual
1 632681 ACCELERATOR PEDAL ASSEMBLY (INCLUDES ITEMS 2 - 13)................. 1
2 626140 ACCELERATOR PEDAL BRACKET ........................................................ 1
3 600019 ROTARY POSITION SENSOR................................................................. 1
4 600543 TORX BOLT, M4 - 0.75 X 12MM LG......................................................... 2
5 612889 PEDAL SWITCH....................................................................................... 1
6 620030 SOCKET HEAD CAP SCREW, M5 - 0.8 X 10MM LG.............................. 2
7 600683 PIN, 4MM X 26MM ................................................................................... 1
8 626142 ACCELERATOR PIVOT SHAFT .............................................................. 1
9 613098 TORSION SPRING, 4.5MM DIA............................................................... 1
10 625731 FLANGED BUSHING, 16MM X 12MM ..................................................... 2
11 604097 REBOUND BUMPER ............................................................................... 1
12 632679 SUSPENDED ACCELERATOR PEDAL................................................... 1
13 610529 ACCELERATOR PEDAL COVER ............................................................ 1
14
15
16 632759 ACCELERATOR BRACKET ........................................................................... 1
17 635195 ACCELERATOR PEDAL CABLE.................................................................... 1
18 10386G2 CLEVIS PIN .................................................................................................... 1
19 632919 ACCELERATOR PEDAL HELPER SPRING .................................................. 1
20 612920 HEX HEAD BOLT, M6 - 1 X 25MM LG............................................................ 3
21 601476 LOCK NUT, M6 - 1 .......................................................................................... 3
