Service Parts Manual
WEATHER PROTECTION
Page W-6
Service Parts Manual
634510 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 628584 TOP CANOPY KIT (INCLUDES ITEMS 2 & 3) .............................................. 1
2 627077 TOP CANOPY............................................................................................ 1
3 628585 HARDWARE KIT (INCLUDES ITEMS 4 - 9) .............................................. 1
4 * WASHER, 1/4" ................................................................................... 12
5 * HEX FLANGED HEAD BOLT, M6 - 1 X 20MM .................................. 8
6 * CLAMP............................................................................................... 4
7 * PUSH RIVETS (NOT ILLUSTRATED)............................................... 4
8 * SPACER............................................................................................. 4
9 * HEX NUT, M6 - 1................................................................................ 4
