Service Parts Manual
WHEELS AND TIRES
Page Y-2
Service Parts Manual
634510 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 631042 BLACK WHEEL AND MUDLITE TIRE ASSEMBLY (STEEL) (DRIVER SIDE)
(INCLUDES ITEMS 3, 4)................................................................................. 2
2 631045 BLACK WHEEL AND MUDLITE TIRE ASSEMBLY (STEEL)
(PASSENGER SIDE) (INCLUDES ITEMS 3, 4).............................................. 2
3 616120 MUDLITE TIRE, 25 X 10 X 12.................................................................... 1
4 631041 WHEEL RIM (STEEL), 12 X 7.................................................................... 1
5
6
7 631048 BLACK WHEEL AND JOURNEY TIRE ASSEMBLY (STEEL)
(INCLUDES ITEMS 8, 9)................................................................................. 4
8 627556 JOURNEY TIRE, 25 X 10 X 12 .................................................................. 1
9 631041 WHEEL RIM (STEEL), 12 X 7.................................................................... 1
10
11
12 630268 BLACK CENTER WHEEL CAP ...................................................................... 4
13 14723G1 LUG NUT, 1/2" - 20 ......................................................................................... 16
To Next Page
