Service Parts Manual
BATTERY SYSTEM
Page C-2
Service Parts Manual
634510 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 641828 BATTERY, 8V.................................................................................................. 6
2 635993 STARTER BATTERY, 12V .............................................................................. 1
3 632784 BATTERY RACK WELDMENT ....................................................................... 1
4 632688 SEAT FRAME WELDMENT............................................................................ 1
5 00440G6 HEX HEAD BOLT, 5/16” - 18 X 2.75" LG........................................................ 2
6 00559G8 FLAT WASHER, 5/16”..................................................................................... 10
7 11098G6 LOCK NUT, 5/16” - 18..................................................................................... 6
8 00438G8 HEX HEAD BOLT, 5/16” - 18 X 1" LG............................................................. 4
9 00715G2 FLANGED HEX HEAD BOLT, 5/16” - 18 X .875" LG ...................................... 4
10 70200G01 TRUSS HEAD MACHINE SCREW, 3/8 -16 X 1" LG ...................................... 2
11
12
13 633190 BATTERY HOLD DOWN WELDMENT, 3 - 8V................................................ 1
14 633191 INNER BATTERY HOLD DOWN BRACKET, 3 - 8V ....................................... 2
15 608513 RUBBER PAD................................................................................................. 4
16 01101G01 TIE DOWN BOLT............................................................................................ 4
17 11027G1 FLANGED LOCK NUT, 5/16” - 18................................................................... 13
18
19
20 629688G01 BATTERY TRAY BRACKET (DRIVER SIDE) ................................................. 1
21 616229 BATTERY HOLD DOWN WELDMENT, 1 - 8V................................................ 1
22 70386G01 TIE DOWN BOLT............................................................................................ 2
23 35493G01 BATTERY DISPOSAL DECAL........................................................................ 7
24
25 634672 BATTERY TRAY FRAME BRACKET.............................................................. 1
26 634673 FRONT BATTERY HOLD DOWN ................................................................... 1
27 604197 BATTERY HOOK BOLT .................................................................................. 2
28 633636 FRONT BATTERY FILL SYSTEM .................................................................. 1
29 548604 FLANGED HEX HEAD BOLT, 5/16” - 18 X 3/4” LG ........................................ 5
30
31 634471 12V STARTER BATTERY TRAY TIEDOWN................................................... 1
