Service Parts Manual
BATTERY SYSTEM
Page C-6
Service Parts Manual
634510 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 634715 WIRE, 2AWG, 71" LG...................................................................................... 2
2 634718 WIRE, 2AWG, 10" LG...................................................................................... 2
3 634717 WIRE, 2AWG, 16" LG...................................................................................... 3
4
5
6 635702 REAR BATTERY FILL SYSTEM..................................................................... 1
7
8
9
10
11
12
13
14 613304 CHARGER RECEPTACLE, 48V..................................................................... 1
15 14601G10 RIVET (ALUMINUM), 5/32"............................................................................. 4
16 635671 CHARGER, 48V, 3 METER CORD................................................................. 1
17 635672 CHARGER, 48V 5.5 METER CORD............................................................... 1
18 622666 WORLD CHARGER, 48V, 3 METER CORD .................................................. 1
19 623013 WORLD CHARGER, 48V, 5.5 METER CORD ............................................... 1
To Next Page
