Service Parts Manual
Page D-2
Service Parts Manual
634510 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 613036G2XX COWL (See COLOR CODE in HOW TO USE Section of Manual)................. 1
2
3
4 626685 FRONT FENDER FLARE (DRIVER SIDE)..................................................... 1
5 626905 FRONT FENDER FLARE (PASSENGER SIDE) ............................................ 1
6 71055G01 RIVET, 3/16" X 1" LG ...................................................................................... 20
7 626663 BBB COWL DECAL ........................................................................................ 1
8 617643 COWL GRILL COVER .................................................................................... 1
9 71597G01 SELF THREADING NUT, 5MM X 10MM......................................................... 2
10 630285 BBB COWL STRIP DECAL............................................................................. 2
11 633268GXX ACCESS COVER (See COLOR CODE in HOW TO USE Section of Manual) 1
12 617533 PUSH RIVET................................................................................................... 9
13 634363 SIDE COWL AMBUSH iS DECAL ................................................................. 2
14 633298 INSTRUMENT PANEL ASSEMBLY (INCLUDES ITEMS 15 - 17).................. 1
15 633297 INSTRUMENT PANEL LARGE CUT OUT ............................................... 1
16 71158G01 CUP INSERT............................................................................................ 1
17 71364G02 J TYPE SPEED NUT, #8 .......................................................................... 5
18 71115G01 TRIM ............................................................................................................... 2
19 75696G01 HOT EXHAUST DECAL.................................................................................. 1
20 16816G2 RATCHET FASTENER, 1/4" X .887" LG......................................................... 4
21 75459G01 GLOVE BOX DOORS (BOTH SIDES)............................................................ 1
22 75459G02 GLOVE BOX DOOR (DRIVER SIDE)............................................................. 1
23 75456G03 GLOVE BOX DOOR (PASSENGER SIDE) .................................................... 1
24
25 74093G01 ENGINE WARNING DECAL........................................................................... 1
26 631494 FRAME WELDMENT...................................................................................... 1
27 635043 BBB DIE CUT DECAL (NOT ILLUSTRATED) ................................................ 1
BODY - FRONT
