Service Parts Manual
Page D-4
Service Parts Manual
634510 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 632345 UPPER FLOOR PANEL.................................................................................. 1
2 70451G03 LOWER FLOOR PANEL................................................................................. 1
3 14601G11 RIVET, 3/16" X 9/16" LG ................................................................................. 14
4
5
6 632254 FLOOR MAT, DIAMOND PLATE..................................................................... 1
7 618886 ROCKER PANEL (DRIVER SIDE).................................................................. 1
8 618885 ROCKER PANEL (PASSENGER SIDE) ......................................................... 1
9 71440G03 PANEL BRACE (DRIVER SIDE)..................................................................... 1
10 71440G04 PANEL BRACE (PASSENGER SIDE) ............................................................ 1
11 15058G6 RIVET (ALUMINUM), .625"............................................................................. 2
12 00789G2 PHILLIPS HEAD SCREW, #10 - 24 X 1 1/4" LG ............................................ 2
13 14390G10 LOCK NUT, #10 - 24 ....................................................................................... 2
14 00660G5 FLAT WASHER (SS), #10............................................................................... 2
15 23726G4 SPACER.......................................................................................................... 4
16
17 634954 SIDE AMBUSH iS DECAL .............................................................................. 2
18 633160GXX SEAT WRAP W/CHARGER RECEPTACLE (See COLOR CODE in HOW TO
USE Section)................................................................................................... 1
19 10570G10 RIVET, 5/32" X 9/16" LG ................................................................................. 8
20 71415G01 ELECTRIC SHOCK WARNING DECAL ......................................................... 1
21 609168G1XX SIDE PANEL (DRIVER SIDE) (See COLOR CODE in HOW TO USE Section) 1
22 609168G2XX SIDE PANEL (PASSENGER SIDE) (See COLOR CODE in HOW TO USE
Section)........................................................................................................... 1
23 10570G12 RIVET, 1/4" X 9/16" LG ................................................................................... 4
24 16469G1 FENDER WASHER, 1/4" ................................................................................ 4
25 10570G11 RIVET, 3/16" X .70" LG ................................................................................... 4
26 71609G01 SEAT HINGE PLATE ...................................................................................... 2
27 71055G01 RIVET, 3/16".................................................................................................... 4
BODY - MID
To Next Page
