Service Parts Manual
FRONT AXLE
Page M-2
Service Parts Manual
634510 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 631489G02 INDEPENDENT DIFFERENTIAL (INCLUDES ITEMS 2 - 3).......................... 1
2 * OIL FILL PLUG......................................................................................... 1
3 * OIL DRAIN PLUG..................................................................................... 1
4 633667 AXLE ASSEMBLY........................................................................................... 2
5
6
7
8
9 00571G3 FLAT WASHER, 3/8"....................................................................................... 8
10 608654 LOCK WASHER, 10MM.................................................................................. 8
11 306835 HEX HEAD BOLT, 3/8" - 16 X 1 1/4" LG......................................................... 8
12 601327 LOCK WASHER, 6MM.................................................................................... 6
13 605741 HEX HEAD BOLT, M6 - 1 X 25MM LG............................................................ 6
14 12719G1 ANTI - SEIZE COMPOUND (NOT ILLUSTRATED)........................................ AR
15 18659G3 THREAD LOCKING ADHESIVE (NOT ILLUSTRATED)................................. AR
To Next Page
