Service Parts Manual
FUEL SYSTEM
Page P-2
Service Parts Manual
634510 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 633216 CARB FUEL TANK ASSEMBLY (WITH SWITCH)
(INCLUDES ITEMS 3, 5 -14) .......................................................................... 1
(FOR VEHICLES MANUFACTURED FROM 24TH NOVEMBER 2014)
2 72229G01 FUEL TANK ADAPTER................................................................................... 1
3 633024G03 PRESS FIT FUEL SENDER..................................................................... 1
4 20048G7 FUEL LEVEL SENDER................................................................................... 1
5 637492 FLUOR FUEL TANK (WITH SENDER UNIT) (INCLUDES ITEMS 6) ...... 1
6 637495 NON FLUOR FUEL TANK (WITH SENDER UNIT) ........................... 1
7 18287G3 SIPHON TUBE ASSEMBLY ..................................................................... 1
8 70988G01 SIPHON TUBE GROMMET ..................................................................... 1
9 606068 ROLLOVER VALVE GROMMET .............................................................. 1
10 606067 ROLLOVER VALVE.................................................................................. 1
11 635688 FUEL TANK CAP (RATCHET).................................................................. 1
12 625826 EPA FUEL TANK LABEL.......................................................................... 1
13 633545 FUEL RETURN GROMMET..................................................................... 1
14 633546 FUEL RETURN FITTING ......................................................................... 1
To Next Page
