Service Parts Manual
MOTOR
Page Q-2
Service Parts Manual
634510 Service Parts Manual
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
1 615557 MOTOR, 72V ................................................................................................. 1
2 629597 MOTOR COVER GASKET ............................................................................. 1
3 629596 MOTOR COVER............................................................................................. 1
4 601327 LOCK WASHER, 6MM.................................................................................... 3
5 616716 HEX HEAD BOLT, M6 - 1 X 16MM LG............................................................ 3
6 12719G1 ANTI SEIZE COMPOUND (NOT ILLUSTRATED).......................................... AR
7 612741 SPEED SENSOR............................................................................................ 1
8 614253 PAN HEAD PHILLIPS SCREW, M6 - 1 X 12MM LG....................................... 1
To Next Page
